型號：MT-GS3428F

品名：28口全千兆以太網交換機

在線詢價

硬件規格
端口	24個10/100/1000M自適應端口 4個10/100/1000M Combo端口
LED指示燈	Power, Link/Act,1000Mbps
尺寸(LWH)	440 mm * 315 mm * 44 mm
工作環境	工作溫度: 0℃~40℃ 存儲溫度: -40℃~70℃ 工作濕度: 10%~90% 無凝結存儲濕度: 5%~90% 無凝結
整機電源	≤24W
支持標準	IEEE 802.3, 802.3u, 802.3x, 802.3af，802.3at CSMA/CD, TCP/IP
基本功能	線速轉發 MAC自動學習與老化 IEEE802.3X全雙工流控與Backpressure半雙工流控
背板帶寬	52Gbps
MAC地址列表	8k
轉發速率	10BASE-T: 14880pps/port 100BASE-TX: 148800pps/port
轉發方式	存儲轉發
軟件規格
VLAN	Port base VLAN ACCESS VLAN TRUNK VLAN HYBRID VLAN 802.1Q tagged VLAN Max. 4094 VLAN
IGMP Snooping	IGMP v1/v2 Snooping Support 256 groups
MAC address administration	MAC address display/inquire Static MAC settings Dynamic MAC address administration MAC address filtering
Loop detection	Support loop detection
storm control	Broadcast/Multicast/Unknown Unicast Storm Control
Link Aggregation	maximum 8 port per group, support 16 group LACP dynamic or static aggregation
Access control	Based on MAC source, destination MAC, MAC source and destination MAC, MAC protocol, source IP access control. Based on the TCP, IP, UDP, IGMP source IP, destination IP, source IP and destination IP access control
Security feature	VLAN port isolation Port +MAC+IP binding
Port Mirroring	- One-to-one - Many-to-one -By mirroring port transmission, receiving and sending and receiving data
network management	Telnet CLI WEB (IP:192.168.1.200 ,username/password: admin/admin)
Port speed limit	Egress and ingress speed limit
DHCPSNOOPING	Prevent illegal DHCP server
Loop detection	Detection of Ethernet loop
ARP attack prevention	To prevent the ARP request deception To prevent the ARP reply to cheat
Jumbo Frames	10K
SNMP	SNMP v2c;conform to RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907 The MIB II;conform to RFC1213 Ethernet MIB;conform to RFC1643 The bridge MIB;conform to RFC1493
RMON	Support group 1, 2, 3, 9
Equipment management	Console Telnet The CLI interface WEB UI Support the ping Check the CPU and memory utilization one key to collect fault
